Description
NominalPressure 250PSI
Design Standard:AWWAC502
Inlet flange size: 6″ (DN150), Main Valve size: 133.4 m / 5-1/4″
One pumper nozzle: 4.5-4NH thread. Two hosenozzles, 2.5-7.5NH threads Other kinds of threads are available
Mechnical connector: AWWA/ ANSI C153 /A21.536, Model No.: MH-1510A
Flange connector: ASME B16.5 CLASS 150/DIN 2501 PN16, Model No:. MH-1510FA
Painting Details: Red Polyurethane paint & Bitumen Black or painting upon request
Note: Each hydrant is supplied with a hydrant wrench
Approvals: UL 246 Listed, FM 1510 Approved
