OS&Y Type Flange end Grooved End Gate Valve
OS&Y Type Flange end Grooved End Gate Valve - Image 2
OS&Y Type Flange end Grooved End Gate Valve - Image 3

$100.00

Category:

Description

Norminal Pressure :200PSI
Groove Standard: Metric or AWWA C606
Both inside and outside the body need Epoxy Resin Coating
Design standard AWWA C515
Flange Standard: ANSI B16.1 Class125 or according to the customer’s requirements
